Machine Design Feature
1
NN bearing designed work spindle offers heavy duty load capacity, optimal rotation accuracy, and high rigidity. The servo motor drive offers steady speed and torque during the grinding operation. A positive air purge system keeps grinding swarf and coolant out of the work head, thus it prolongs its life.
2
The structure of cross slides is made of Meehanite cast iron. Its good thermostability compensates for temporary temperature changes. (Roller bearing and straight lead rail with Heidenhain linear scale).
3
NN bearing designed work spindle with high power motor provides enough power to outer diameter 510mm of wheel head, and improves processing efficiency. The angle of wheel head could be choose as 0 or 20 degree.
4
Oil-bath tail stock remains lubrication and makes the machine more durable. Tailstock taper adjustment feature makes workpiece setting faster.
5
Bath type of machine base is made in Meehanite cast iron, which experience natural aging and twice stress relief to make machine base itself more stable and durable.
Specification
| EGP-2550CAMCNC | EGP-2575CAMCNC | EGP-25100CAMCNC |
|
| Swing Over Table | Ø250 mm | Ø250 mm | Ø250 mm |
| Distance Between Centers | 500 mm | 750 mm | 1000 mm |
| Max. Grinding Diameter | Ø230 mm | Ø230 mm | Ø230 mm |
| Max. Load Held Between Center | 100 kg | 100 kg | 100 kg |
| Net Weight | 4000 kg | 4000 kg | 4000 kg |
| Gross Weight | 4000 kg | 4500 kg | 4500 kg |
| Size | 3170x2500x2050 mm | 3670x2500x2050 mm | 4340x2500x2050 mm |
Learn More About Our Product
For more detailed information, please download our catalog. The catalog includes standard accessories, optional accessories, and a comprehensive specification guide to help you better understand our product’s features!
